Typical Properties of Silicone Elastomer Clear TS9933
|
Before Curing |
|
|
Item |
Index |
|
Appearance |
Clear |
|
Mix ratio |
10:1 |
|
Viscocity (25℃，MPa) |
A: 1200 B: 10 |
|
Property( g/cm3) |
A:1.1+0.02 B:0.95+0.02 |
|
Tack free time( min ) |
40-60 |
|
After Curing |
|
|
Item |
Index |
|
Hardness( Shore )≤ |
35 |
|
Tensile Strength ( PSI) |
980 |
|
Breaking Elongation ( % ) ≥ |
120 |
|
Volume resistivity ( Ω.cm3 ) ≥ |
1×1015 |
|
Break voltage（KV/mm）≥ |
14 |
|
Dielectric constant（1MHZ） |
3.5 |
|
Temperature range( ℃ ) |
-45～150 |
Application of Silicone Elastomer
◆ LED Lighting encapsulation
◆ Power supply
◆ Connectors
◆ Sensors
◆ Industrial control
◆ Transformers
Description of Silicone Elastomer
Tensan silicone elastomer consists of two liquid components A and B. When the two components are thoroughly mixed at a weight ratio of 10: 1, the mixed liquid will solidify into a flexible elastomer at room temperature. The duration of application and the curing time at room temperature are independent of the amount of material.
Packing Information of Silicone Elastomer
1. For mix ratio 10:1
A 20KG / B 2KG
Storage and Validity of Silicone Elastomer
Stored in room temperature, and in a cool, ventilated, dry place.
Shelf life: 6 month
